Multi-storey building

The Shard 32 London Bridge Street 10 280.jpg Terrace photos.jpg Norfolk terrace270.jpg

Contents

[edit] Introduction

A single-storey building is building consisting of a ground storey only. See: Single-storey building definition for more information.

A multi-storey building is a building that has multiple storeys, and typically contains vertical circulation in the form of ramps stairs and lifts. Multi-storey buildings range from 2 storeys to more than 150 storeys.

Depending on their height, multi-storey buildings may have particular considerations and requirements in relation to:

[edit] Classifications

Classifications of multi-storey buildings include:

  • Low-rise: a building which is not tall enough to be classified as high-rise.
  • Mid-rise: buildings of five to ten storeys, equipped with lifts.
  • High-rise: more than 7 to 10 storeys.
  • Skyscraper: 40 storeys or more.
  • Supertall: exceeding 300m.
  • Megatall: exceeding 600m.

[edit] Structural types

The basic types of multi-storey structure (which may be used in combination) include:

[edit] Framed structure

Network of columns and connecting beams form the structural 'skeleton' of the building and carry loads to the foundations.

[edit] Propped structure

Uses a cantilever slab or platform as the seating for columns. It utilises an internal core and external propped columns.

[edit] Suspended structure

Has an internal core and horizontal floors which are supported by high-strength steel cables hung from cross beams at the top.

[edit] Cantilever structure

Has an internal core from which beams and floors cantilever. This removes the necessity for columns.

[edit] Braced structure

Bracing is used to give stability so that columns can be designed as pure compression members. The beams and columns that form the frame carry vertical loads, and the bracing system carries the lateral loads. Braced frames reduce lateral displacement, as well as the bending moment in columns, they are economical, easily erected and have the design flexibility to create the strength and stiffness required.

For more information, see Braced frame structures.

[edit] Shear wall structure

Composed of stiff braced (or shear) panels which counter the effects of lateral and wind pressures. The pressures are transmitted to the shear walls by the floors.

For more information, see Shear wall.

[edit] Core structure

Utilises a stiff structural core which houses lifts, stairs, and so on. Wind and lateral pressures are transmitted to the core by the floors.

For more information, see Shell and core.

[edit] Hull core structure

Also known as ‘tube-in-tube’ and consists of a core tube inside the structure which holds services such as utilities and lifts, as well as a tube system on the exterior. The inner and outer tubes interact horizontally as the shear and flexural components of a wall-frame structure.

For more information, see Tube structural system.
