RICS publishes Land Measurement for Planning and Development Purposes
In May 2021, guidance on the measurement of land for development projects such as new housing and commercial development was published by the Royal Institution of Chartered Surveyors (RICS) which defines common measurements used across the built environment and associated metrics such as density.
Titled Measurement of Land for Planning and Development Purposes, it provides clear definitions for measurements widely used in the property and built environment sectors, advocating consistency worldwide. Five core definitions have now been formalised by RICS to assist with the global measurement of land. They are:
- Land Ownership Area (LOA): an area of land, measured on a horizontal plane, which is held in a single legal interest or title by one or more legal owners, which may be the subject of a proposed or actual sale, letting or other disposal, valuation or compulsory purchase, and which may comprise all or part of that single legal interest or title.
- Site Area (SA): the total land area on which development authorisation is sought, measured on a horizontal plane.
- Net Development Area (NDA): the extent of the Site Area upon which one or more buildings or other operations and their ancillary space can be built, measured on a horizontal plane.
- Plot Ratio (PR): the ratio of total development floor area to SA. Development floor area may be measured as gross external area (GEA) or gross internal area (GIA) but whichever is used or modifications of them should be clearly stated.
- Floor Area Ratio (FAR) and Floorspace Ratio (FSR) are similar terms, used interchangeably in some jurisdictions to reference the same point. For consistency, PR should be used wherever possible. Where jurisdictional requirements are for the use of either FAR or FSR, PR should be reported as well.
- Site Coverage (SC): the ratio of ground floor area (measured in accordance with GEA) to SA, expressed as a percentage.
A key difference with the guidelines is that calculations of density should now always be expressed in terms of Gross Density (based on SA), rather than on a Net basis, with Net Density providing an additional and complementary metric for understanding the intensity of development of a site.
This article originally appeared on the CIAT website under the headline, 'RICS launches new global guidance for "Land Measurement"'. It was published on 25 May 2021.
