Last edited 16 Jan 2021
Fire spread in buildings
Fire occurs as a result of a series of very rapid chemical reactions between a fuel and oxygen that releases heat and light. For combustion to occur, oxygen, heat and a fuel source must all be present. Flames are the visible manifestation of combustion. For more information see: Fire.
Fire spread describes the travel of fire from one area to an adjoining area. Fire spread can occur within buildings and between buildings when combustible material in one area ignites and the fire eventually spreads to an adjoining area.
- The degree of fire separation (fire compartmentation) that exists.
- The combustibility of the materials present (some materials such as soft furnishings may burn at faster rates than others).
- The presence of air/oxygen (draughts and convection currents can fuel fires to burn more rapidly).
- The presence of active fire fighting systems to detect and suppress fires.
 How a fire spreads
- Direct contact: materials adjacent to each other ignite through a domino-type effect;
- Radiation: when a fire is strong enough, it can emit sufficient radiated heat to ignite combustible materials that are not in direct contact with it. This process is similar to sunlight directed through a lens onto dry straw – the straw will eventually ignite.
- Conduction: heat is transferred through materials that ignite adjacent materials that are in contact. A wall may get so hot that it ignites the wallpaper on the other side.
- Convection: currents of air rise above a fire and may concentrate at an upper limit, eg beneath a ceiling. When substantial hot gas and smoke has accumulated, the temperature at the upper level rises to such an extent that it can set materials on fire, thereby causing a secondary fire and possibly a flashover (below).
- Flashover: the hot air and gases accumulated by convection may eventually start to descend to a lower level through radiation and at sufficiently high temperatures (around 500°C) that may make combustible materials start emitting gases and resulting in spontaneous ignition.
- Backdraught: a fire in a room with little oxygen will start to peter out but if a door opens or glass in a window breaks, the sudden inflow of air/oxygen can reignite the fire with explosive effect.
The methods of ensuring fire safety are:
- Prevention: Controlling ignition and fuel sources so that fires do not start.
- Communication: If ignition occurs, ensuring occupants are informed and any active fire systems are triggered.
- Escape: Ensuring that occupants of buildings and surrounding areas are able to move to places of safety.
- Extinguishment: Ensuring that fires can be extinguished quickly and with minimum consequential damage.
- Containment: Fires should be contained to the smallest possible area, limiting the amount of property likely to be damaged and the threat to life safety.
The spread of fire can be restricted by sub-dividing buildings into a number of discrete compartments. These fire compartments are separated from one another by compartment walls and compartment floors made of a fire-resisting construction which hinders the spread of fire.
 Related articles on Designing Buildings Wiki
- Automatic fire detection and alarm systems, an introductory guide to components and systems BR 510.
- External fire spread, Supplementary guidance to BR 187 incorporating probabilistic and time-based approaches.
- Fire in buildings.
- Fire compartmentation.
- Fire detection and alarm system.
- Fire protection engineering.
- Fire safety design.
- Understanding the factors affecting flashover of a fire in modern buildings.
